GNSS Ceramic Patch Antenna (U.FL Connector)
High-performance 28dBi GNSS ceramic patch antenna designed for GPS and GLONASS applications. Features U.FL (IPEX Gen 1) connector with 3 cm RF0.81 coaxial cable. Supports dual-frequency operation at 1575.42MHz (GPS L1) and 1561MHz (GLONASS G1). Omnidirectional radiation pattern ensures reliable satellite signal reception. Ideal for navigation systems, asset tracking, IoT devices, and location-based applications.
Electrical Parameters
|
Center Frequency |
1575.42/1561 MHz |
|
Antenna Bandwidth |
1500–1610 MHz |
|
Antenna Gain |
28 dBi |
|
VSWR |
< 2 |
|
Polarization |
Vertical |
|
Radiation Pattern |
Omnidirectional |
|
Input Impedance |
50 Ω |
|
Maximum Power |
5 W |
Other Parameters
|
Antenna Dimensions |
20.0 × 6.0 × 6.5 mm |
|
Antenna Thickness |
6.5 mm |
|
Coaxial Cable Length |
3 cm |
|
Antenna Material |
Ceramic |
|
Coaxial Cable Type |
RF0.81 |
|
Connector Type |
U.FL (IPEX Gen 1) |
|
Operating Temperature |
-30 ℃ ~ +80 ℃ |
